High Quality Forklift Concrete Bell Type Block Clamps For Sale

características

1.Structure with complete steel and high strength meets special requirements.
2.Structural designation makes field of vision widely for operator.
3.Used removable type article wear-resisting, after wearing is easy to replace economic and practical.
4.Can be rotated and field to make effective if needed.

Especificación

Capacity Range

(kg)

Modelo

Holding Width

(mm)

Altura de elevación

(mm)

Tilting Angle

Rotating Angle

Telescopic Length

(mm)

5000-8000

BTC-GX

Min

240x4=960

Max

240x6=1140

5600

6-12°

90-120°

400-800

Vídeos

Obter a capacidade real do montacargas e accesorios do fabricante de carretillas elevadoras.

Holding width refers to the length of the standard bricks for 200-240mm, 4-6 bricks, the width of the size need to be measured and confirmed.
Póñase en contacto coas vendas de HUAMAI

Aplicación

Bell type block clamps can complete function of hoisting, tilting, rotation, scaling, clamp, excellent comprehensive performance.

Skilled application of hydraulic technology, with hydraulic components protection, can fully meet the needs of the working condition of brick industry.

Detalles rápidos

Lugar de orixe: Fujian, China (continente)
Nome da marca: HUAMAI
Model Number: BTC-GX
Product Name: Bell type block clamps
Model: BTC-GX
Lifting Height (mm): 5600mm
Tilting Angle: 6-12°
Rotating Angle: 90-120°
Telescopic Length (mm): 400-800mm
Capacity Range (kg): 5000-8000

Block clamp

Aplicacións

1.Concrete block clamp can efficiently handle various types of solid, regular cubic goods under normal temperature.

2.Widely used in construction material, metallurgy industries for handling concrete blocks, cement bricks, carton cubes, etc.

3.The high structural strength and durability ensura the safe, productive application and long service life.

características

1.The item doesn't need to be put on pallet to be transported. If need be, they can be put on a pallet and after than they can be handled by a traditional forklift too.

2.Proven durable T-beam arm aluminium frame construction.

Rodamento de brazo deslizante superior para unha longa vida útil.

4.Regenerative hydraulic valving for optimal arm speed.

5.Durable contact pads, reliable clamping.

6.Excellent driver visibility.
