Carretilla elevadora

Introdución Push Pull Products.

---

Push Pull is a very usefull forklift attachment.Palletless handling cargos in a unit by utilizing a cheap slipsheet.This forklift attachment can save an expensive pallet and reduce damage to cargo during handling. Forklift Push is only have a push action forced by hyraulic.It is proper for loading cargo in unit,baged and boxed. Forklift Push Pull have two actions one is push as we talked above and the other is pulling. Push Pull is good at cargo loading and diacharging. The push pull forklift attachment are used in various industries such as food, beverage, glassware, building material, agricultural, paper, chemical and the automotive parts industry.Custom push pull attachment is available.Please consult our Riggerte sales if you have any questions.

Vídeos

---

Nº de pedido do catálogo	Capacidade @ Centro de carga (kg @ mm)	Clase de montaxe	Tamaño da placa WxL (mm)	Trazo (mm)	Ancho mínimo do carro do camión (mm)	Centro vertical de gravidade VCG (mm)	Grosor efectivo ET (mm)	Centro horizontal de gravidade HCG (mm)
PPQ-1.6TE-B455	1600@600	II	455x1220	1270	790	300	165	235
PPQ-1.6TE-B380	1600@600	II	380x1220	1270	790	300	165	220
PPQ-2TE-B455	2000@600	II	455x1220	1270	790	300	165	260
PPQ-2TE-B380	2000@600	II	380x1220	1270	790	300	165	245

Carretilla elevadora Características Push Pull

---

High visibility pantograph, gripper jaw and faceplateFull bottom taper/adjustable platens4° tilting faceplateChamfered platen corners and gripper jaw design protects the slip sheet High strength, rigid pantograph for safe load packingT-1 steel platens"Cushion" cylinders reduce operating noise Simplified hydraulic circuit Sideshift J-plate is automatically engaged when the push/pull is set on the truck carriageNo false carriage is required on quick disconnect models Sideshift function is available for custom.

Carretilla elevadora Opcións Push Pull

Acopladores hidráulicos de cambio rápido

Placas de cara estendidas

Trazos de apertura estendidos

As placas faciais e os tamaños dos platens son opcionais

Grupo de adaptación de solenoides montado nun anexo

Tenedores e grupos de garfos múltiples

Montaxe de clase III

Carretilla elevadora Push Pull Política de garantía

Todos os novos produtos de Riggerte (Xiamen) Forklift Truck Attachment Co., Ltd, incluídos os accesorios, as tenedores e as pezas de servizo, están garantidos durante 12 meses seguintes á data da entrega ao transportista principal, ou 2000 horas de operación, segundo remate a primeira alternativa. Para obter máis detalles sobre a garantía, non dubide en contacto connosco.

Carretilla elevadora Push Pull Suxestión de selección de produtos

No caso de que os clientes non saiban que modelo é correcto.Por favor envíe unha solicitude a Riggerte Sales. Sería moito mellor se poida proporcionar os seguintes elementos na súa consulta.

Marca e nome do modelo de carretilla elevadora que vai instalar un accesorio para tirar.

Necesitamos coñecer a capacidade de carga de carretillas elevadoras, a presión de caudal hidráulico e as funcións.

Cargo unit packing information including gross weight,unit packing dimension,and cargo materials. As much details as you can offer.

Forklift truck working conditions.

---
